Sacrificial Anode Protection Magnesium Tank Anode For Cathodic Protection

Name: Sacrificial Anode Protection Magnesium Tank Anode For Cathodic Protection
Brand: High Broad
Price: 1 USD

China Sacrificial Anode Protection Magnesium Tank Anode For Cathodic Protection wholesale

Brand Name : High Broad

Model Number : magnesium soil anode/magnesium hull anode

Certification : ISO DNV CE

Place of Origin : CHINA CHANGSHA

MOQ : 1/KG

Price : negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram,PayPal,Credit Card

Supply Ability : 5000 tons/year

Delivery Time : 1 work days

Packaging Details : On pallet with steel bundles

az63 magnesium anode : magnesium soil anode/magnesium hull anode

MgMn magnesium anode : magnesium soil anode/magnesium hull anode

magnesium hull anode : for steel hull of boat in fresh water

magnesium soil anode : for Hulls of ships, barges, tugs and boats

Specification : GB or U. S. Mil-A or W or As per request

Function : Corrosion Protection

Cast Magnesium Anodes : Az63 Cast Magnesium Anodes for Oil transportation and gas transmission in underground and fresh water

Extruded Magnesium Anode : Extruded Magnesium Anode Rod for Water Heater

Application : Oil transportation and gas transmission in underground and fresh water

Contact Now

Magnesium Anode cathodic protection

Primarily designed for tank interiors, tank anodes utilize a longitudinal steel strap core for bolting or welding to the steel surface.

Magnesium Anode Application:

Corrosion protection for

Electric water heater

Oil transportation and gas transmission in underground and fresh water

Line pipe for draining away water

Underground cable

Chemical industry

Communication

Dock and harbour

Boats and ships

Reservoir gate.

Chemical Component

Type	Chemical Component
	Alloy element				Impurity not more than
	Al	Zn	Mn	Mg	Fe	Cu	Ni	Si
MGAZ1	5.3-6.7	2.5-3.5	0.15-0.6	balance	0.005	0.01	0.001	0.05
MGAZ2	2.7-3.5	0.7-1.3	0.15-0.6	balance	0.005	0.01	0.001	0.05
MGM	<0.05	<0.03	1.2-2.0	balance	0.005	0.02	0.001	0.05
MG	<0.02	<0.03	<0.01	>99.9	0.005	0.004	0.001	0.01

Electrochemical Performance

Type	open circuit potential		current efficiency		Producing electricity
	-V·Min		%·Min		(A·h)/g·Min
	3%NaCl Solution 3mA/cm2	Soil 0.03mA/ cm2	3%NaCl Solution 3mA/ cm2	Soil 0.03mA/ cm2	3%NaCl Solution 3mA/ cm2	Soil 0.03mA/ cm2
MGAZ1	1.55	1.50	55	50	1.20	1.10
MGAZ2	1.60	1.55	60	55	1.30	1.20
MGM	1.60	1.55	55	50	1.20	1.10
MG	1.65	1.60	50	45	1.10	1.00

The common type of underground pipe line, the outerwall of storage tank and other underground metal structure

Type	Specification L(upper+down)H	(kg) Weight
MG-22	700×(130+150)×125	22.0
MG-14	700×(100+110)×105	14.0
MG-11	700×(90+100)×90	11.0
MG-8	700×(75+85)×80	8.0
MG-4	700×(55+60)×55	4.0
MG-2	350×(55+60)×55	2.0

Sacrificial Anode Protection Magnesium Tank Anode For Cathodic Protection
